Racor 230R2 Fuel Filter Water Separator.
The 230R Diesel Spin-On Series fuel filter / water separator comes standard with an integral priming pump, a see-thru contaminant bowl and can operate in applications up to 30 PSI. Applications include light-duty and medium-duty marine engines, trucks, construction and agricultural vehicles, and other diesel-powered equipment.
Features:
Flow Rate: 30 gph (114 lph)
Includes 2 micron Aquabloc Spin-On Element - R20S - NON UL RATED
Number of Ports: 1 Inlet / 2 Outlet
Port Size: 1/4"-18 NPTF (Port fittings sold separately)
Integral Primer Pump Included: Hand Plunger Priming Pump (Diesel)
Heater Power Rating: No Heater
Mounting: Bracket Included
Head Material: Aluminium Alloy
Bowl Material: Clear Engineering Plastic - RK 22350-02
Maximum Working Pressure: 30 psi (2.07 bar)
Clean Pressure Drop: 0.31 psi (0.02 bar)
For use with medium duty diesle marine engines and above deck installations
The lower the micron rating, the finer the filtration. Follow your engine manufacturer's recommendation for fuel filter micron rating.
S = Secondary/Final 2 micron (Brown)
T = Primary or Secondary/Final 10 micron (Blue)
P = Primary 30 micron (Red)
The 230R Diesel Spin-On Series fuel filter / water separator comes standard with an integral priming pump, a see-thru contaminant bowl and can operate in applications up to 30 PSI. Applications include light-duty and medium-duty marine engines, trucks, construction and agricultural vehicles, and other diesel-powered equipment.
Features:
For use with medium duty diesle marine engines and above deck installations
The lower the micron rating, the finer the filtration. Follow your engine manufacturer's recommendation for fuel filter micron rating.
| Brand | Racor |
|---|---|
| Cross Reference / Specs | USE WITH: |
