Bennett Marine CC3003-P Actuator Upper Hinge with Coil ? Port 2019-Present

Bennett Marine CC3003-P Actuator Upper Hinge with Coil – Port 2019-Present.

**Manufactured AFTER March 2019**

Upper actuator hinge for use with Bennett Trim Tabs. For use with both Port and Starboard sides.

Features:

Sensor Coil: Manufactured AFTER March 2019 is Black and white

Sensor Rod: Manufactured AFTER March 2019 is Flat edges on both sides

Note: Do not interchange rods. Newer actuator upper hinges should only use rods with flat edges on both sides. Older actuator upper hinges should only use sensor rods with one pointed edge (pointed edge faces down)

Note: The standard stroke for hydraulic actuators is 2.5". If you are not sure of the proper stroke of the actuator, see the identifying illustration in the Replacing Actuator Upper Hinge with Sensor Wire

Plastic Spacer: The spacer was not present BEFORE March 2019. Note: The plastic spacer may be shipped detached from the upper hinge. The flanged edge will be installed facing up

Wire Color: Grey

Wire Length: 30'
